SAUNAONES® Contrast Therapy Dual Tub
true dual-zone hot and cold system with independent temperature control
purpose-built for contrast therapy and daily recovery protocols
outdoor-rated construction designed for extreme climates and winters
seamless transitions between heat and cold with no downtime
true dual-zone contrast system
separate hot and cold zones operate independently with dedicated heating and cooling. both maintain target temperature at all times, so transitions are instant with no reheating, no drift, and no wait.
extreme outdoor rating: -30°C (-22°F)
engineered for permanent outdoor installation through full Canadian winters. built-in antifreeze protection and auto defrost handle freeze-thaw cycles without manual intervention or seasonal shutdown.
1.5 HP continuous flow cooling
higher output than standard 1 HP systems. maintains cold zone performance even in low ambient temperatures, delivering consistent 5 to 40°C across the full range.
hot zone with 12 integrated massage jets
dedicated hot zone supports muscle relaxation and contrast recovery with adjustable jet flow. holds up to 40°C independently of the cold side.
ozone purification + shared filtration
centralized filtration serves both zones from a single maintenance point. ozone sanitation keeps water clean with minimal manual upkeep. one routine, not two.
integrated LED lighting
built-in LED lighting in both zones for low-light sessions, early mornings, and evening recovery.
quiet, efficient operation
engineered for background operation during sessions. no disruptive noise during recovery.
plug-and-play power options
runs on two standard 115V outlets (one per zone) or a single 220V / 15A connection. no specialized electrical work required.
system type
dual-zone outdoor contrast therapy system (independent hot and cold immersion)
cold zone dimensions：
51 in (L) x 32.5 in (W) x 26 in (H)
hot zone dimensions：
75 in (L) x 32 in (W at seats) / 27 in (W at middle) x 25.5 in (H)
combined footprint：
approx. 85 in x 85 in (216 cm x 216 cm)
cold zone temperature range：
5 to 40°C (41 to 104°F)
hot zone temperature range：
up to 40°C (104°F)
cold zone water capacity：
approx. 455 L (120 gal)
hot zone water capacity：
approx. 492 L (130 gal)
chiller
1.5 HP with continuous flow system
hot zone jets
12 integrated massage jets
dry weight
340 kg (750 lbs)
estimated filled weight
900 to 1,000+ kg
minimum operating temperature
rated for outdoor use down to -30°C (-22°F)
power options
115V x 2 (separate plugs for hot and cold) or 220V / 15A combined
filtration and purification
ozone sanitation + centralized shared filtration with easy-access filter housing
drainage
exterior bottom drain
